Technical
Data (for some standard sizes)
|
Model |
H (mm) |
L (mm) |
I (mm) |
Tubes |
Heat Output (Watt)
75/65-20 EN442 |
| TW760500 |
760 |
500 |
450 |
16 |
360 |
| TW900500¡¡ |
900 |
500 |
450 |
18 |
388 |
| TW1200550 |
1200 |
550 |
500 |
26 |
621 |
| TW1500600 |
1500 |
600 |
550 |
32 |
816 |
| TW1800650 |
1800 |
650 |
600 |
38 |
1108 |
( Data based on
horizontal tubes with Ø 25mm, vertical with 35 x 40mm ) Notes: 1.
The horizontal tubes could be made with diameter of Ø 20mm,
Ø 22mm or Ø25mm, their thickness could be 1mm,1.2mm or
1.5mm. 2.
The vertical tubes could be made with specification of 35 x 40mm or
30 x 40mm, their thickness is 1.5mm. 3.
Any sizes could be available upon client's
requests. 4.
Working pressure is 7 bars and testing pressure is 10.5 bars for the
model made of tube with thickness of 1mm. Working pressure
will be 10 bars and testing pressure could be 15 bars for the model
made of tube with thickness of 1.5mm.
Maximal Working temperature: 95¡æ
. ¡¡
|
